Rexroth Piston PUMP
$599.00
Rexroth axial piston pump series：
A4V series (variable displacement pump)
A4VG series (closed-loop pump)
A10VSO series (variable displacement pump)
A7V series (oblique shaft pump)
Rexroth axial piston pump series
A4V series (variable displacement pump)
Features: Swashplate design, flow rate proportional to rotational speed, wide pressure range.
Specifications:
Displacement: 10~1000 cm³/rev
Pressure rating: up to 400 bar (system pressure)
Speed range: 500~3000 rpm
Control mode: manual, hydraulic, electric proportional control
Applications: injection molding machines, die-casting machines, construction machinery (such as excavators, cranes).
A4VG series (closed-loop pump)
Features: Designed specifically for closed hydraulic systems, integrating a makeup pump and flushing valve.
Specifications:
Displacement: 12~250 cm³/rev
Pressure rating: up to 450 bar
Speed range: 1000~3000 rpm
Applications: Mobile machinery (such as pavers and rollers), ship steering gears.
A10VSO series (variable displacement pump)
Features: Compact design, low noise, high efficiency.
Specifications:
Displacement: 18~180 cm³/rev
Pressure rating: up to 350 bar
Control mode: pressure, flow rate, and power control are optional
Applications: machine tools, plastic machinery, light construction machinery.
A7V series (oblique shaft pump)
Features: Inclined shaft structure, strong impact resistance, suitable for high-pressure conditions.
Specifications:
Displacement: 28~1000 cm³/rev
Pressure rating: up to 700 bar
Speed range: 500~2000 rpm
Applications: metallurgical equipment, high-pressure water jet, test bench.
